XENO Micro frame


QuattroVolante  XENO Micro

1.5mm thick 3K Carbon fiber main plate, 1mm cf side panels

FC TPU mount included for smooth, vibrations free, flights

Suggested motors (1S version): 0705 15000KV with 40mm propellers and 1S battery (350-600mAh)

Suggested motors (2S version): 0905 10000KV or 1102/03 with 40mm propellers (max 1.9″) and 2S battery (350-450mAh)

The kit is designed and optimized to use max 20mm (16x16mm holes) fc and same size 4in1 esc

11xx  1.5mm frame version will fit up to 16×16 fc and 1.9″ props

11xx  2mm frame version will fit up to 20×20 fc and 2″ props

Special frame version for 08xx motors will fit up to 65mm propellers

Maximum props size for 0905 or 06xx/07xx  versions  is 40mm

Fits small cameras (max width 15.5mm) like Runcam Nano, Runcam Race Nano, CADDX Turbo EOS2

Using the recommended parts, AUW should be around 30 grams

Carbon fiber prop guards  are available here

Motors and electronics not included

SKU: N/A Category:

Additional information

Weight 21 g

Black, Green, Orange, Red, White, Yellow

Hole pattern

08xx(3 holes) standard, 08xx(3 holes) 65mm props, 0703/05, DYS 0905, 11xx (1.5mm), 11xx(2mm)
